Характеристики
| Параметр |
Значение |
| Производитель: |
Inogeni |
| MPN: |
INOGENI-4KX-PLUS |
| Модель: |
Inogeni INOGENI-4KX-PLUS |
| Connector & Video Resolutions:: |
1 x HDMI 1.4a 4K UHD (3840/4096x2160), 1440p, 1080p, 720p, 1080i, 480p, 576p, 1280x1024, 1280x960, 1 |
| Frame Rates:: |
60, 59.94, 50, 30, 29, 97, 25, 24, 23.98 Hz for all resolutions except 4K=30Hz max. |
| Colour Space:: |
RGB, YCbCr, 4:4:4, and 4:2:2 (4K=RGB) |
| Sampling Rate:: |
297 MHz |
| Embedded Audio:: |
Ch 1&2 48kHz LPCM |
| USB - Connector & Video Resolutions:: |
1 x USB type B (USB 3.0/2.0) 4K UHD (3840/4096x2160), 1440p, 1080p, 720p, 1080i, 480p, 576p, 1920x12 |
| USB - CODECs:: |
YUY2 4:2:2 and NV12/I420/YV12 4:2:0 for USB 3.0 MJPEG for USB 2.0 |
| USB - Video Scaler:: |
Automatic hardware based |
| USB - Colour Space Conversion:: |
Automatic hardware based |
| USB - Sampling Conversion:: |
Automatic hardware based |
| USB - Frame Rate Conversion:: |
Automatic hardware based |
| Analog Audio I/O:: |
2-channel LPCM audio from HDMI and/or from Audio Jack |
| Audio Input Connector:: |
1 x 3.5mm, MIC or line-level, unbalanced |
| Audio Output Connector:: |
1 x 3.5mm, line-level, unbalanced CH1&2 48kHz LPCM feed from HDMI |
| Mixing Functionality:: |
HDMI audio and analog audio inputs are mixed over the USB input i |
| Operating System:: |
No driver installation necessary. Windows 7 and above (32/64-bi |
| Minimum Host Requirements:: |
USB 2.0 port - We recommend USB 3.0 for uncompressed video 4GB RA |
| Supported Cameras:: |
Cameras (or video source) with an HDMI output |
| Software Compatibility:: |
Compatible to: Teams, Zoom, Webex, Google Meet, etc. |
| Power Supply:: |
Powered by USB 4.5W (5V, 900mA) or by external power supply 5W (5V, 1A) |
| Operating Temperature:: |
0° to 45°C 32° to 113°F |
| Storage Temperature:: |
-40° to 105°C -40° to 221°F |
| Relative Humidity:: |
0% to 90% non-condensing |
| Универсальный товарный код: |
51497285142 |
